10.3.2 WIRING HARNESS FOR THE BATTERY BOX
10.3.2.1 POWER MANAGER HARNESS
G01
G02
G03
G04
G05
G06
G07
G09
G10
G11
G12
G13
G14
G16
Connect to the 8pin connector of the battery box
Connect to the power manager
Connect to Hall Sensor
Connect to the main contactor
Connect to the negative pole of the battery pack
Connect to the main contactor terminal (positive pole of the battery pack)
Connect to the charging port
Connect to the main contactor terminal (output side)
Connect to the sleep-mode relay
Connect to the charging relay
Connect to the relay of the power manager
Connect to the relay of the ignition switch
Connect to the relay of the controller
Connect to the positive current fuse 10A
10.3.2.2 BATTERY SAMPLING HARNESS
G01
G02
G03
G04
Connect the sampling port of 24pin module
Connect the sampling port of 28pin module
Connect to the temperature sampling harness of the power manager
Connect to the voltage sampling harness of the power manager
