BYD PMW20 - Page 98

PMW20
194
2. Forklift-mounted +CAN
PMW20
195
Current
Hall
Signal
+15V
-15V
Hall Current
Charging-discharging Contactor
KM1
Temperature
Sampling
Voltage
Sampling
Relay of the Power Manager
Charging Relay
Sleep-mode Relay
Controller Relay
Ignition Relay
Positive Current Fuse 15A
B-
B+
Battery
Backup
Unit
Power Manager A BMS1
KM3
1.37Kw
120
?
Motor Brake
Limit Switch of the Fork
Horn
Horn
Relay
Main Contactor
1.2Kw
24VDC
Lift Motor
Handle
Quick
Reverse
Handle
Limit
Switch
Lowering
Solenoid
Valve
Display
Drive Motor
KEY Fuse
COMBIACX Main Controller CT1
U V W
Time
-delay
Relay
Emergency Stop Switch
Ignition Switch
Ignition Switch Fuse
Release
Motor
Brake
SM-PMW202020001-EN
SM-PMW202020001-EN
Forklift-mounted Charger
