Cafection TOTAL LITE - Internal View

TOTAL LITE Revision 1
SERVICE MANUAL FOR INNOVATION TOTAL LITE Single-Cup Brewer
11
4.3 Internal View
Reference Drawings
Filter paper
Soluble mixing
chamber
Brewer
Spout
Waste basket
Main board
(See P. 16)
Front panel
Coffee grinder
(Behind the protector)
COM connection
Fan
Coffee
Hot water
Soluble products
#1 and #2
Soluble canisters
