TOTAL LITE Revision 1
SERVICE MANUAL FOR INNOVATION TOTAL LITE Single-Cup Brewer
16
4.7.1 Main Board (PCB) Descriptions
Interactive switches and buttons
1.Setup Button (SW1) White
Pressing this button gives you access to
the tally counter data.
2.Service button (SW2) Black
Pressing this button will enter / exit to the
service mode. See section 4.2 for details.
Toggles switches are not used in the Total
Lite, but must be position correctly for
proper operation. The two left switches
must point to the left and the two right
switches must point to the right.
Green LEDs
The green leds will illuminate to indicate
the alarm that has been triggered.
DS18 - Drip tray overow
DS13 - Cam switch
DS14 - Always off if lter paper required
DS15 - Water level switch ON
DS19 - Water level switch OFF
DS16 - N/A
DS17 - N/A
DS20 - N/A
DS25 - N/A
DS27 - N/A
DS26 - N/A
DS24 - N/A
DS23 - N/A
Red LEDs
The red leds will illuminate to indicate
the part is in use.
DS2 - Coffee #1 motor
DS3 - Coffee #2 motor
DS4 - Soluble #1 motor
DS5 - Soluble #2 motor
DS6 - Coffee hot water
DS7 - Soluble hot water
DS21 - Chute Solenoïde
DS22 - Brewer motor
DS10 - Inlet valve
DS8 - Hot water
DS9 - Brewer motor
DS12 - N/A
DS11 - Grinder
DS29 - Whipper
DS31 - Coffee #3
