SERVICE MANUAL FOR INNOVATION TOTAL LITE Single-Cup Brewer
9
4 REFERENCE DRAWINGS
4.1 External View
Reference Drawings
Drip tray grill
Drip tray
Back splash
Touchscreen
Door lock
Metal door
Plastic front
(Fascia)
Plastic top lid
3 Whole bean
canister
