Cafection TOTAL LITE - Adjusting the Tank Overflow Float; Beans Canister Installation; Install the 3 Beans Canister

TOTAL LITE Revision 1
SERVICE MANUAL FOR INNOVATION TOTAL LITE Single-Cup Brewer
39
7.4.2 Adjusting the Tank Overow Float
It is important to verify that the oat is positioned appropriately in
the overow cup since it can move around in transportation. If this
oat is not in place the switch will not be activated and the unit will
automatically shut down sensing an overow situation.
It is important to verify that the overow cup is in place with the
highest side in the front and secured with the tape. If you need
to remove this cup, please make sure that you replace it with the
highest section facing the front and the overow tube in the cup.
This will ensure that the oat will “oat” and will activate the overow
switch if there is a problem.
7.5 3 Beans canister installation
7.5.1 Install the 3 Beans Canister
Unpack the 3 beans canister.
Remove the tape from transmission.
Install the canister on the shelf by aligning
the 3 transmissions of the canister with the
3 motors already xed on the shelf.
Initial Setup
Transmissions
3 Beans canister
Motors
