TOTAL LITE Revision 1
SERVICE MANUAL FOR INNOVATION TOTAL LITE Single-Cup Brewer
40
7.5.2 Lock the 3 Bean canister
Pivot the 2 locks vertically, so they clip on the
metal pins.
7.5.3 Install the Plastic Top tting part
Place the part on the back of the 3 beans
canister with the 6-32 screw already in place.
7.5.4 Install the Plastic Top
Simply place the plastic top on the top of the
machine as illustrated.
Lock
Plastic top
tting part
Initial Setup
