SERVICE MANUAL FOR INNOVATION TOTAL LITE Single-Cup Brewer
54
8.7.3 Coffee Brewer
Rinsing the Brew Chamber:
Frequency: Weekly or every 200 cycles
See section 8.5 for automatic rinsing function.
WARNING! make sure to place a container
large enough (size is specied on the screen)
. BE CAREFUL because water is VERY HOT!
Brewer Funnel
Frequency: As needed or weekly
If there are coffee grounds accumulated, remove the assembly for manual cleaning under hot water:
1. Remove the brown water hose;
2. Lift off the funnel and pull out of the brew chamber;
3. Rinse thoroughly under hot water;
4. Air dry completely;
5. Reinstall all parts in the reverse order.
6. Order a large coffee to conrm that all parts have been replaced correctly.
Brewer Assembly Cleaning
Frequency: Monthly or every 1,000 cycles
In order to maintain optimal performance of the brewer
assembly, we recommend that it be removed
from the unit and cleaned / rinsed with hot water.
(see section 10.3 for instructions on removing the brewer)
1. Rinse thoroughly under hot water to remove visible soil;
2. Lift off the funnel and pull out of the brew chamber;
3. Rinse thoroughly under hot water;
4. Air dry completely;
5. Reinstall all parts in the reverse order.
6. Order a large coffee to conrm that all parts have been
replaced correctly.
Brew Chamber
Brewer Funnel
Brewer Chamber
Hose Support
Cleaning & Sanitizing
