4.4 Brewer Assembly
The platinum brewing system is in a class of it’s own in the single cup coffee business and is
specically designed for Cafection units. Its vacuum extraction process, joined with a high quality lter
paper, brews a coffee of unsurpassed quality to meet the taste prole of the most dicerning coffee
drinkers. Best of all, this is available for every cup of coffee at any time of day. See the following page for
the description of the brewing process.
Brew chamber
Cylinder
Piston
Coffee exit
Aluminum frame
Wheel
Serial number
Brewer funnel
Yoke
Reference Drawings
