Page 27 - Manual FA01358-EN - 07/2019 - © CAME S.p.A. - The contents of this manual may be changed, at any time, and without notice. - Translation of the original instructions
U4
Decoding the
radio-frequency
code
Select the type of transmitter radio coding that you wish to save on the control
board.
⚠ When you select a radio coding, all saved transmitter are automatically
deleted.
TWIN's coding lets you save multiple users with the same key (Key block).
1 = all of the series (default)/2 = only Rolling Code series /3 = only TWIN
series
A1 Intended use
Set the intended use.
1 = Standard installation
The maximum lift is 20 kg beyond the necessary lifting of the window/
door.
2 = Private installation
The maximum lift is 40 kg beyond the necessary lifting of the window/
door.
A2 Motor test
Test to verify the gear motor's proper direction of rotation (see the MOTORS
TEST paragraph).
OFF = Deactivated / ON = Activated
A3
Gate-swing
calibration
Automatic calibration of the door travel (see the CALIBRATION DOOR TRAVEL
paragraph)
OFF = Deactivated / ON = Activated
A4
Resetting
parameters
Caution! For restoring the default factory settings and deleting the gate travel
setting.
OFF = Deactivated / ON = Activated
A5 Maneuver count
For viewing the maneuvers count performed to date by the gear motor (00 =
100 maneuvers; 010 = 1,000 maneuvers; 100 = 10,000 maneuvers; 999 =
99,900 maneuvers; CSI = maintenance job).
A6
Adjusting the
motor torque
For adjusting the motor torque from 1 minimum to 5 maximum.
1 / 2 / 3 / 4 / 5 (default)
H1 Version View the fi rmware version.
Page 27 - Manual FA01358-EN - 07/2019 - © CAME S.p.A. - The contents of this manual may be changed, at any time, and without notice. - Original instructions
