Page 5 - Manual FA01358-EN - 07/2019 - © CAME S.p.A. - The contents of this manual may be changed, at any time, and without notice. - Translation of the original instructions
Technical data
Type VER10DMS VER13DMS
Protection rating (IP)
40
Power supply (V - 50/60 Hz) 230 AC
Input voltage motor (V) 24 DC
Stand-by consumption (W) 5 7
Stand-by consumption RGP1 (W) 0.5
Maximum power of the accessories (W) 40
Maximum power (W) 180 280
Maneuvering speed (m/min) 7
Traction force (N) 1,000 1.300
Acoustic pressure LpA (dBA) ≤70
Cycles/hour 30
Operating temperature (°C) -20 to +55
Apparatus class
Weight (Kg) 5.7 5.8
KEY
This symbol shows which parts to read carefully.
⚠
This symbol shows which parts describe safety issues
☞
This symbol shows which parts to tell users about.
The measurements, unless otherwise stated, are in millimeters.
DESCRIPTION
Automated operator featuring a control panel with encoder for sectional and overhead garage doors.
Intended use
The VER10DMS / VER13DMS operators are developed to drive overhead and sectional garage-doors in private
homes and apartment buildings.
Do not install of use this device in any way, except as specifi ed in this manual.
Limits to use
Type VER10DMS VER13DMS
Door's max. surface area (m
2
)1821
Counter-weighted overhead door's max. weight (m) 2.40
Maximum height of spring-balanced overhead doors (m) 3.25
Maximum height of sectional doors (m) 3.20
Page 5 - Manual FA01358-EN - 07/2019 - © CAME S.p.A. - The contents of this manual may be changed, at any time, and without notice. - Original instructions
