ProtoCessor 1991 Tarob Court Milpitas, California 95035 USA Web:
www.protocessor.com
Tel: (408) 964-4444 Fax: (408) 964-4425 email: support@protocessor.com
Camus ProtoNode Startup
G id
Appendix F. Reference
Specifications
Electrical Connections
One 6-pin Phoenix connector with:
RS-485 port (+ / - / gnd)
Power port (+ / - / Frame-gnd)
One 3-pin Phoenix connector with
RS-485 port (+ / - / gnd)
One Ethernet 10/100 BaseT port
One 6-pin Phoenix connector with:
RS-485 port (+ / - / gnd)
Power port (+ / - / Frame-gnd)
One 2-pin Phoenix connector with:
One FTT-10 LonWorks port
One Ethernet 10/100 BaseT port
Approvals
CE certified; UL 916 approved; WEEE compliant; REACH compliant;
EN 50491-3 and CSA C22-2 standards; FCC Class A Part 15;
DNP 3.0 conformance tested; RoHS 3 compliant; CSA 205 approved
11.5 cm L x 8.3 cm W x 4.1 cm H (4.5 x 3.2 x 1.6 in.)
-40°C to 75°C (-40°F to167°F)
EN61000-4-2 ESD EN61000-4-3 EMC EN61000-4-4 EFT
5 - 90% RH (non-condensing)
(Specifications subject to change without notice)
Figure 47: Specifications
Appendix F.1.1. Compliance with UL Regulations
For UL compliance, the following instructions must be met when operating ProtoNode.
• The units shall be powered by listed LPS or Class 2 power supply suited to the expected operating
temperature range.
• The interconnecting power connector and power cable shall:
o Comply with local electrical code
o Be suited to the expected operating temperature range
o Meet the current and voltage rating for ProtoNode
• Furthermore, the interconnecting power cable shall:
o Be of length not exceeding 3.05m (118.3”)
o Be constructed of materials rated VW-1, FT-1 or better
• If the unit is to be installed in an operating environment with a temperature above 65 °C, it should
be installed in a Restricted Access Area requiring a key or a special tool to gain access.
• This device must not be connected to a LAN segment with outdoor wiring.
