Valiant Modbus RTU Mappings to BACnet, Metasys N2, Modbus TCP/IP &
LonWorks
Point Name R/W
BACnet
Object
Type
BACnet
Object
ID/ N2
Address
N2 Data
Type
Modbus Register
(dec)
LonWorks Name LonWorks SNVT Notes
Outdoor_temp
R
AI
1
AI
126
nvoOutdrTmp_XXX
SNVT_temp_p
BM_TotalSystemSetpoint
W
AV
2
AO
503
nvoBMTotSySP_XXX
SNVT_temp_p
BM_CM_PowerLevel
R
AI
3
AI
20001
nvoBMCMPwLvl_XXX
SNVT_count_f
BM_CM_Setpoint
R
AI
4
AI
20002
nvoBMCMSP_XXX
SNVT_temp_p
BM_CM_SystemTempSensor
R
AI
5
AI
20021
nvoBMCMSyTSn_XXX
SNVT_temp_p
In Cascade mode only
BM_CM_OutdoorTempSensor
R
AI
6
AI
20022
nvoBMCMOtTSn_XXX
SNVT_temp_p
BM_CM_PumpStatus
R
AI
7
AI
20061
nvoBMCMPmpSt_XXX
SNVT_count_f
BM_Boiler_1_Available
R
AI
8
AI
20101
nvoBM1Avail_XXX
SNVT_count_f
In Cascade mode only
BM_Boiler_2_Available
R
AI
9
AI
20102
nvoBM2Avail_XXX
SNVT_count_f
In Cascade mode only
BM_Boiler_3_Available
R
AI
10
AI
20103
nvoBM3Avail_XXX
SNVT_count_f
In Cascade mode only
BM_Boiler_4_Available
R
AI
11
AI
20104
nvoBM4Avail_XXX
SNVT_count_f
In Cascade mode only
BM_Boiler_5_Available
R
AI
12
AI
20105
nvoBM5Avail_XXX
SNVT_count_f
In Cascade mode only
BM_Boiler_6_Available
R
AI
13
AI
20106
nvoBM6Avail_XXX
SNVT_count_f
In Cascade mode only
BM_Boiler_7_Available
R
AI
14
AI
20107
nvoBM7Avail_XXX
SNVT_count_f
In Cascade mode only
BM_Boiler_8_Available
R
AI
15
AI
20108
nvoBM8Avail_XXX
SNVT_count_f
In Cascade mode only
BM_Boiler_1_Active
R
AI
16
AI
20133
nvoBM1Act_XXX
SNVT_count_f
In Cascade mode only
BM_Boiler_2_Active
R
AI
17
AI
20134
nvoBM2Act_XXX
SNVT_count_f
In Cascade mode only
BM_Boiler_3_Active
R
AI
18
AI
20135
nvoBM3Act_XXX
SNVT_count_f
In Cascade mode only
BM_Boiler_4_Active
R
AI
19
AI
20136
nvoBM4Act_XXX
SNVT_count_f
In Cascade mode only
BM_Boiler_5_Active
R
AI
20
AI
20137
nvoBM5Act_XXX
SNVT_count_f
In Cascade mode only
BM_Boiler_6_Active
R
AI
21
AI
20138
nvoBM6Act_XXX
SNVT_count_f
In Cascade mode only
BM_Boiler_7_Active
R
AI
22
AI
20139
nvoBM7Act_XXX
SNVT_count_f
In Cascade mode only
BM_Boiler_8_Active
R
AI
23
AI
20140
nvoBM8Act_XXX
SNVT_count_f
In Cascade mode only
BM_Boiler_1_HasError
R
AI
24
AI
20165
nvoBM1Error_XXX
SNVT_count_f
In Cascade mode only
BM_Boiler_2_HasError
R
AI
25
AI
20166
nvoBM2Error_XXX
SNVT_count_f
In Cascade mode only
BM_Boiler_3_HasError
R
AI
26
AI
20167
nvoBM3Error_XXX
SNVT_count_f
In Cascade mode only
BM_Boiler_4_HasError
R
AI
27
AI
20168
nvoBM4Error_XXX
SNVT_count_f
In Cascade mode only
BM_Boiler_5_HasError
R
AI
28
AI
20169
nvoBM5Error_XXX
SNVT_count_f
In Cascade mode only
BM_Boiler_6_HasError
R
AI
29
AI
20170
nvoBM6Error_XXX
SNVT_count_f
In Cascade mode only
BM_Boiler_7_HasError
R
AI
30
AI
20171
nvoBM7Error_XXX
SNVT_count_f
In Cascade mode only
BM_Boiler_8_HasError
R
AI
31
AI
20172
nvoBM8Error_XXX
SNVT_count_f
In Cascade mode only
BM_Boiler_1_ReqService
R
AI
32
AI
20197
nvoBM1ReqSr_XXX
SNVT_count_f
In Cascade mode only
BM_Boiler_2_ReqService
R
AI
33
AI
20198
nvoBM2ReqSr_XXX
SNVT_count_f
In Cascade mode only
BM_Boiler_3_ReqService
R
AI
34
AI
20199
nvoBM3ReqSr_XXX
SNVT_count_f
In Cascade mode only
BM_Boiler_4_ReqService
R
AI
35
AI
20200
nvoBM4ReqSr_XXX
SNVT_count_f
In Cascade mode only
