Camus Hydronics ProtoNode FPC-N34 User Manual

Page 63 of 87
ProtoCessor 1991 Tarob Court Milpitas, California 95035 USA Web: www.protocessor.com
Tel: (408) 964-4444 Fax: (408) 964-4425 email: support@protocessor.com
BM_Boiler_5_ReqService
R
AI
36
AI
20201
nvoBM5ReqSr_XXX
SNVT_count_f
In Cascade mode only
BM_Boiler_6_ReqService
R
AI
37
AI
20202
nvoBM6ReqSr_XXX
SNVT_count_f
In Cascade mode only
BM_Boiler_7_ReqService
R
AI
38
AI
20203
nvoBM7ReqSr_XXX
SNVT_count_f
In Cascade mode only
BM_Boiler_8_ReqService
R
AI
39
AI
20204
nvoBM8ReqSr_XXX
SNVT_count_f
In Cascade mode only
BM_ResetCurveBoilerDesign
W
AV
40
AO
21001
nvoBMRsCvBDs_XXX
SNVT_temp_p
BM_ResetCurveBoilerMildWeather
W
AV
41
AO
21002
nvoBMRsCvBWt_XXX
SNVT_temp_p
BM_ResetCurveDesignMildWeather
W
AV
42
AO
21003
nvoBMRsCvDWt_XXX
SNVT_temp_p
BM_ResetCurveOutdoorDesign
W
AV
43
AO
21004
nvoBMRsCvODs_XXX
SNVT_temp_p
BM_WarmWeatherShutdown
W
AV
44
AO
21005
nvoBMWmWtSht_XXX
SNVT_temp_p
BM_ResetCurveBoilerMaximum
W
AV
45
AO
21006
nvoBMRsCvBMx_XXX
SNVT_temp_p
BM_ResetCurveBoilerMinimum
W
AV
46
AO
21007
nvoBMRsCvBMn_XXX
SNVT_temp_p
BM_NightSetBack
W
AV
47
AO
21008
nvoBMNtStBck_XXX
SNVT_temp_p
BM_Boiler_PowerLevel
R
AI
48
AI
30001
nvoBMBlPwLvl_XXX
SNVT_count_f
BM_Boiler_CalcSetpoint
R
AI
49
AI
30002
nvoBMBlClcSP_XXX
SNVT_temp_p
BM_Boiler_SystemTempSensor
R
AI
50
AI
30021
nvoBMBlSyTpS_XXX
SNVT_temp_p
In Cascade mode only
BM_Boiler_DHWSensor
R
AI
51
AI
30022
nvoBMBlDHWSn_XXX
SNVT_temp_p
BM_Boiler_SystemCHPumpStatus R AI 52 AI 30061 nvoBMBlSCHPp_XXX SNVT_count_f
0 = off
1 = on
BM_Boiler_DHWPumpStatus
R
AI
53
AI
30062
nvoBMBlDHWPp_XXX
SNVT_count_f
BM_Boiler_BurnHours
R
AI
54
AI
30081
nvoBMBlBrnHr_XXX
SNVT_time_hour
BM_Unit_11_available
R
AI
55
AI
30101
nvoBMUn11Avl_XXX
SNVT_count_f
In Cascade mode only
BM_Unit_12_available
R
AI
56
AI
30102
nvoBMUn12Avl_XXX
SNVT_count_f
In Cascade mode only
BM_Unit_13_available
R
AI
57
AI
30103
nvoBMUn13Avl_XXX
SNVT_count_f
In Cascade mode only
BM_Unit_14_available
R
AI
58
AI
30104
nvoBMUn14Avl_XXX
SNVT_count_f
In Cascade mode only
BM_Unit_15_available
R
AI
59
AI
30105
nvoBMUn15Avl_XXX
SNVT_count_f
In Cascade mode only
BM_Unit_16_available
R
AI
60
AI
30106
nvoBMUn16Avl_XXX
SNVT_count_f
In Cascade mode only
BM_Unit_17_available
R
AI
61
AI
30107
nvoBMUn17Avl_XXX
SNVT_count_f
In Cascade mode only
BM_Unit_18_available
R
AI
62
AI
30108
nvoBMUn18Avl_XXX
SNVT_count_f
In Cascade mode only
BM_Boiler_Address
R
AI
63
AI
31001
nvoBMBlrAddr_XXX
SNVT_count_f
BM_HoursSinceLastService
R
AI
64
AI
33001
nvoBMHrLstSv_XXX
SNVT_time_hour
BM_HoursTillServiceIsRequired
R
AI
65
AI
33002
nvoBMHrTlSrv_XXX
SNVT_time_hour
BM_OverdueCounter0
R
AI
66
AI
33006
nvoBMOvrCt0_XXX
SNVT_time_hour
BM_OverdueCounter1
R
AI
67
AI
33007
nvoBMOvrCt1_XXX
SNVT_time_hour
BM_OverdueCounter2
R
AI
68
AI
33008
nvoBMOvrCt2_XXX
SNVT_time_hour
BM_OverdueCounter3
R
AI
69
AI
33009
nvoBMOvrCt3_XXX
SNVT_time_hour
BM_OverdueCounter4
R
AI
70
AI
33010
nvoBMOvrCt4_XXX
SNVT_time_hour
BM_OverdueCounter5
R
AI
71
AI
33011
nvoBMOvrCt5_XXX
SNVT_time_hour
BM_OverdueCounter6
R
AI
72
AI
33012
nvoBMOvrCt6_XXX
SNVT_time_hour
BM_OverdueCounter7
R
AI
73
AI
33013
nvoBMOvrCt7_XXX
SNVT_time_hour
BM_OverdueCounter8
R
AI
74
AI
33014
nvoBMOvrCt8_XXX
SNVT_time_hour
BM_OverdueCounter9
R
AI
75
AI
33015
nvoBMOvrCt9_XXX
SNVT_time_hour
BM_OverdueCounter10
R
AI
76
AI
33016
nvoBMOvrCt10_XXX
SNVT_time_hour
BM_OverdueCounter11
R
AI
77
AI
33017
nvoBMOvrCt11_XXX
SNVT_time_hour
BM_OverdueCounter12
R
AI
78
AI
33018
nvoBMOvrCt12_XXX
SNVT_time_hour
BM_OverdueCounter13
R
AI
79
AI
33019
nvoBMOvrCt13_XXX
SNVT_time_hour
