Camus ProtoNode Start-up Guide

Page 15 of 87

4 INTERFACING PROTONODE TO DEVICES

4.1 Connection from

DynaFlame/Dynaforce/Advantus/Avenger to

ProtoNode

The DynaFlame®/Dynaforce® terminals J3-MB2 (+, -) are connected to the Protonode as

shown.

• Boiler 1: MB1 Modbus Address = MB2 Modbus Address = 1

• Boiler 2: MB2 Modbus Address = MB2 Modbus Address = 2 etc.
