Disassembly/Assembly > List of Parts > Main Unit > Lists of SADF Unit
Disassembly/Assembly > List of Parts > Main Unit > Lists of SADF Unit
List of Parts
Main Unit
■
Lists of DADF Unit
[1]
[2]
[3]
[4]
No. Name Reference Remarks
[1] Original Sensor -
[2] DADF Motor -
[3] Original Edge Sensor -
[4] DADF Solenoid
F-4-1
■
Lists of SADF Unit
[1]
[2]
[3]
No. Name Reference Remarks
[1] Original Sensor -
[2] Original Edge Sensor -
[3] SADF Motor -
F-4-2
