Canon imagePROGRAF iPF685 - Carriage; Roll Cover (Inside)

g Cleaning Brush
When cleaning inside the printer under the Top Cover, use this brush to sweep away paper dust on the Platen.
Roll Cover (Inside)
Roll Cover (Inside)
a
Roll Holder
Load the roll on this holder.
b
Holder Stopper
Secure rolls on the Roll Holder with this part.
c Roll Loading Slots
Slide the Roll Holder along these slots.
d Roll Holder Slot
Load the Roll Holder into this holder slot.
Carriage
Carriage
iPF685
Roll Cover (Inside)
User's Guide
Printer Parts Printer parts
