Printheads
Printheads
Printhead ........................................................................................................................................................ 546
Checking for Nozzle Clogging ......................................................................................................................... 546
Cleaning the Printhead ................................................................................................................................... 547
Replacing the Printhead ................................................................................................................................. 548
Printhead
Printhead
When purchasing, check the Model number.
Shape Model number
PF-04
Note
•
For instructions on replacing the Printhead, see "Replacing the Printhead." âž” P.548
Checking for Nozzle Clogging
Checking for Nozzle Clogging
If printing is faint or affected by banding in different colors, make sure the Printhead nozzles are clear by printing a
test pattern to check the nozzles.
Note
•
Nozzles are periodically checked to ensure they are clear. Configure the settings on the Control Panel menu in
Nozzle Check. (See "Menu Settings.") ➔P.418
Paper to Prepare
When Using Rolls An unused roll at least 254.0 mm (10.00 in) wide
When Using Sheets One sheet of unused paper of at least A4/Letter size
1
Load paper.
•
Attaching the Roll Holder to Rolls âž” P.338
•
Loading Rolls in the Printer âž” P.341
•
Loading Sheets in the Printer âž” P.359
2
On the Tab Selection screen of the Control Panel, press â—€ or â–¶ to
select the Settings/Adj. tab ( ).
Note
•
If the Tab Selection screen is not displayed, press the Menu button.
3
Press the OK button.
The Set./Adj. Menu is displayed.
Printhead
iPF685
User's Guide
Maintenance and Consumables Printheads
546
