2.4.4 Maintenance Cartridge Relay PCB
2.4.4.1 Maintenance cartridge relay PCB components
0023-2553
F-2-33
a) EEPROM (IC1)
The 256-KB EEPROM stores all information written to the EEPROM on the main controller PCB.
IC 1
