Chapter 4
4-54
4.3.18 Draining the ink
0023-3348
There are two ways to drain the ink passage of inks: automatic and manual.
Be sure to drain the ink from the ink passage to prevent ink leakage before disassembling any component of the ink passage or reshipping the printer.
1. Automatic Ink Drain
Execute Automatic Ink Drain by selecting "Set./Adj. Menu" > "Prep.MovePrinter" from the main menu.
Execute Automatic Ink Drain once again if the printer shuts down due to a power failure or any other trouble before the operation completes.
2. Manual Ink Drain
Drain the ink passage of inks manually if any electrical component in the printer fails or firmware malfunctions or if the printer fails to be powered on.
1) Remove left/right cover, left/right ink tank cover. See "Disassembly/Reassembly > Points to Note on Disassembly/Reassembly > External Covers".
2) Remove the ink tanks.
3) Move the carriage to above the platen. See "Disassembly/Reassembly > Points to Note on Disassembly/Reassembly > Opening the caps and moving the wiper
unit".
4) Release the printhead fixer lever.
5) Open the ink supply valve/subtank air passage valve to allow the inks to flow into the ink tank unit waste ink tray.
MEMO:
When supplying the ink to the printer after the manual ink drainage, return the printer to the normal condition, and then turn ON the power supply without the
printhead installed. And according to the message, execute the installation of the printhead.
To Next Page
