1.4 Detailed Specifications
1.4.1 Interface Specifications
0023-2577
a. USB (standard)
(1) Interface type
USB 2.0 Hi-Speed (Full speed (12 Mbits/sec), High speed (480 Mbits/sec))
(2) Data transfer system
Control transfer
Bulk transfer
(3) Signal level
Compliant with the USB standard.
(4) Interface cable
Twisted-pair shielded cable, 5.0 m max.
Compliant with the USB standard.
Wire materials: AWG No.28, data wire pair (AWF: American Wire Gauge)
AWG No.20 to No.28, power distribution wire pair
(5) Interface connector
Printer side: Series B receptacle compliant with USB standard
Operation panel LCD (160 X 128 dots), 13 keys, 5 LEDs
- Panel language
English
- Message language
English, German, French, Italian, Spanish, Chinese, Korean, Russianand
and Japanese
Printhead/Ink Tank type Printhead and separate ink tanks
Printhead PF-04
Structure: Integrated six-color assembly
Number of nozzles: 5,120 for MBK, 2,560 for other each color
Ink tank [PFI-107/8107] MBK, BK, C, M, Y
Ink type: Pigment ink (MBK)
Dye ink (BK, C, M, Y)
Ink tank capacity: [PFI-107/8107] 130 ml
(Ink tanks supplied with the printer contain 90 ml of each color.)
Detection functions (Cover
system)
Upper cover open/closed detection: Yes
Ink tank cover open/closed detection: Yes
Detection functions (Ink passage
system)
Ink tank presence/absence detection: Yes
Remaining ink level detection (dot count and electrode): Yes
Maintenance cartridge presence/absence detection: Yes
Used ink tank full detection: Yes
Ink supply Valve open/closed detection: Yes
Detection functions (Carriage
system)
Printhead presence/absence detection: Yes
Carriage position detection: Yes
Carriage home position detection: Yes
Printhead temperature detection: Yes
Printhead height detection: Yes
Non-discharging nozzle detection: Yes
Non-discharging nozzle backup feature: Yes
Ambient temperature/humidity detection: Yes
Detection functions (Paper path
system)
Paper presence/absence detection: Yes
Paper width detection: Yes
Skew detection: Yes
Paper leading edge and trailing edge detection: Yes
Release lever position detection: Yes
Remaining roll media detection: Yes
Feed roller rotation detection: Yes
Roll holder rotation detection: Yes
Cutter positin detection: Yes
Operating noise Operating: Approx. 47dB (A) or less
Standby: Approx. 35dB (A) or less
Operating environment Temperature: 15 to 30 degrees centigrade
Humidity: 10% to 80%RH without dew condensation
Print quality guaranteed
environment
Temperature: 15 to 30 degrees centigrade
Humidity: 10% to 80%RH
Power supply 100-240 VAC (50/60 Hz)
Power consumption (Maximum) During printing: Max. 140 W
Power consumption In power save (sleep) mode:
5W or less
During standby: 0.5W or less
Printer unit dimensions
(WxDxH)
997mm(W) x 698mm(D) x 507mm(H) (printer alone)
997mm(W) x 870mm(D) x 1062mm(H) (with ST-26 or ST-27 stand and
opening the output stacker)
997mm(W) x 1100mm(D) x 1062mm(H) (with ST-27 stand and setting
to the extended position B)
Weight Approx. 43kg (printer alone)
Approx. 54kg (with ST-26 or ST-27 stand and without printhead and ink
tank)
Package dimensions (WxDxH) /
Weight
1127mm x 830mm x 773mm (printer alone, with the palette), approx.
72kg
1073mm x 766mm x 263mm (ST-26 stand), approx. 15kg
1083mm x 766mm x 350mm (ST-27 stand alone), approx. 19kg
For US model: 1127mm x 830mm x 1058mm (with the stand and the
palette), approx. 89kg
