Chapter 7
7-21
1) PRINTER: Counters related to product life
2) CARRIAGE: Counters related to carriage unit
3) PURGE: Counters related to purge unit
4) CLEAR: Counters related to counter initialization
Display Description Unit
LIFE TTL Cumulative number of printed media (equivalent of A4) sheets
LIFE ROLL Cumulative number of printed roll media (equivalent of A4) sheets
LIFE CUTSHEET Cumulative number of printed cut sheets (equivalent to A4) sheets
LIFE A-F Cumulative number of printed media for environments A to F sheets
POWER ON Cumulative power-on time (excluding the sleep time) Hours
W-INK Remaining capacity of the maintenance cartridge %
CUTTER Number of cutting operations (count as 1 by moving back and forth) Times
WIPE Number of wiping operations Times
SLEEP ON Cumulative sleep-on time Hours
Display Description Unit
PRINT Cumulative printing time Hours
DRIVE Cumulative carriage moving time Hours
CR COUNT Cumulative carriage scan count (count as 1 by moving back and forth) Times
CR DIST. Cumulative carriage scan distance (count as 1 by moving 210mm) Times
PRINT COUNT Cumulative print end count (count as 1 by capping) Times
Display Description Unit
CLN-A-1 Cumulative number of automatic cleaning 1 (normal suction) operations Times
CLN-A-2 Cumulative number of automatic cleaning 2 (ink level adjusting) operations Times
CLN-A-3 Cumulative number of automatic cleaning 3 (initial filling) operations Times
CLN-A-6 Cumulative number of automatic cleaning 6 (strong normal suction) operations Times
CLN-A-7 Cumulative number of automatic cleaning 7 (aging) operations
CLN-A-10 Cumulative number of automatic cleaning 10 (ink filling after secondary transportation) operations Times
CLN-A-11 Cumulative number of automatic cleaning 11 (ink filling after head replacement) operations Times
CLN-A-15 Cumulative number of automatic cleaning 15 (dot count small suction) operations Times
CLN-A-16 Cumulative number of automatic cleaning 16 (sedimented ink agitation) operations Times
CLN-A-17 Cumulative number of automatic cleaning 17 (small suction) operations Times
CLN-A-TTL Total number of automatic cleaning operations Times
CLN-M-1 Cumulative number of manual cleaning 1 (normal suction) operations Times
CLN-M-4 Cumulative number of manual cleaning 4 (ink draining from head after head replacement) operations Times
CLN-M-5 Cumulative number of manual cleaning 5 (ink draining from head and tube before transportation ) operations Times
CLN-M-6 Cumulative number of manual cleaning 6 (normal strong suction) operations Times
CLN-M-TTL Total number of manual cleaning operations Times
Display Description Unit
CLR-INK CONSUME Cumulative count of ink section consumption amount clearing Times
CLR-MTC EXC. Cumulative count of maintenance cartridge replacement count clearing Times
CLR-HEAD EXC. Cumulative count of printhead replacement count clearing Times
CLR-UNIT CR-1 EXC. Cumulative count of unit CR-1(carriage unit bushing) replacement count clearing Times
CLR-UNIT CR-2 EXC. Cumulative count of unit CR-2(fexible cable unit) replacement count clearing Times
CLR-UNIT CR-3 EXC. Cumulative count of unit CR-3(linear encoder sensor/linear scale/shaft cleaner)
replacement count clearing
Times
CLR-UNIT CR-4 EXC. Cumulative count of unit CR-4(carriage height changing cam) replacement count
clearing
Times
CLR-UNIT CR-5 EXC. Cumulative count of unit CR-5(multi sensor) replacement count clearing Times
CLR-UNIT SP-1 EXC. Cumulative count of unit SP-1(ink tube unit) replacement count clearing Times
CLR-UNIT PG-1 EXC. Cumulative count of unit PG-1(purge unit) replacement count clearing Times
CLR-UNIT HMa-1 EXC. Cumulative count of unit HMa-1(head management sensor) replacement count clearing Times
CLR-UNIT MT-1 EXC. Cumulative count of unit MT-1(carriage motor) replacement count clearing Times
CLR-UNIT PL-1 EXC. Cumulative count of unit PL-1(feed motor) replacement count clearing Times
CLR-UNIT Mi-1 EXC. Cumulative count of unit Mi-1(mist fan/mist exhaust duct) replacement count clearing Times
CLR-UNIT CT-1 EXC. Cumulative count of unit CT-1(cutter) replacement count clearing Times
CLR-UNIT WF-1 EXC. Cumulative count of unit WF-1(ink absorber under the maintenance cartridge unit)
replacement count clearing
Times
CLR-UNIT WF-2 EXC. Cumulative count of unit WF-2(platen exhaust duct) replacement count clearing Times
CLR-FACTORY CNT. For factory Times
