CaptiveAire TANK - Page 31

31
Figure 32 - Double Stack Pizza Oven
Figure 33 - Triple Stack Pizza Oven
1. Overlapping Nozzle (OL-F)
2. Conveyor Opening
3. Install union in pipe leading to nozzle to allow
for appliance removal and cleaning.
1
1
1
1
2
2
3
1. Overlapping Nozzle (OL-F)
2. Conveyor Opening
3. Install union in pipe leading to nozzle to allow
for appliance removal and cleaning.
4. Additional drop for third nozzle. No more than
two nozzles are allowed per drop.
2
1
1
1
1
1
1
2
2
3
4
