CaptiveAire TANK - CORE Board Faults

54
CORE Board Faults
When there are no faults in the fire system, the LED light will stay solid. When there is a fault, the LED light
will flash with a short break. Count the flashes then wait for the short break to determine the fault.
NOTE: CORE Boards with software version 1.68 and prior will use one brief flash every 3-seconds
to indicate there are no faults in the fire system.
Catastrophic faults
Critical faults
Important faults
Number of
Flashes
Fault Condition Corrective Action
1 Invalid Activation Check for external voltage being applied at J3-7 and J3-10.
2 Release Solenoid Check solenoid and wiring to solenoid, replace as needed.
3 Pressure Switch Check solenoid and wiring to solenoid, replace as needed.
4 Auxiliary Fault
Check supervised Pressure Regulating Valves (optional) and
Pressure Switches (optional).
5 Microcontroller Fault Replace CORE printed circuit board.
Number of
Flashes
Fault Condition Corrective Action
6N/A
N/A
7 Supervised Loop
Check the wiring to all the manual actuation devices
(push/pull stations) and fire sensors for shorts to ground,
replace as needed.
Refer to “Supervised Loop Electrical Details” on page 46.
Number of
Flashes
Fault Condition Corrective Action
8 Ground Fault
Check the wiring to all the manual actuation devices
(push/pull stations) and fire sensors for shorts to ground,
replace as needed.
Refer to “Supervised Loop Electrical Details” on page 46.
9N/A N/A
10 Battery Voltage Low
Replace batteries, wait for batteries to recharge if there was a
power failure.
11 AC Power Failure Check breakers, call power company.
12 Door Tamper Switch Close cabinet door.
13 Test Mode Place switch in armed position when testing is complete.
14 CORE Interlock
Check Dip Switches on all boards and RS-485 network wires
connecting boards.
15
Fault on Hood in
Network
Check all hoods in CORE network for faults.
16
Fault on PCU in
Network
Check all PCUs in CORE network for faults.
