8200-M585-O1 Rev D
210 I
nstallation & Technical
15
INSTALLATION, CONT.
AC Input Relay Board(s), Cont.
IMPORTANT! AC INPUT RELAYS ARE VOLTAGE DEPENDENT. A DIFFERENT
RELAY IS REQUIRED FOR 115 VAC AND 230 VAC!
Figure No.
5
R
e
l
a
y Box
A
ssem
b
ly
RB4-ACIN
or
R
B8-
AC
I
N
22
5 Indicator – P1
7
Figure No.
8
210 Indicator – P3
Figure No. 10
Relay Box Assembly RB4-ACIN or RB8-ACIN
Relay Box Assembly RB4-ACINV or RB8-ACINV
20
22
Table of Contents
Table of Contents
5
Specifications
7
Standard Features
8
Optional Features
8
Precautions
9
Site Preparation Requirements
11
Installation
13
Mounting
13
Load Cell Cable Connection for RFI Suppression
14
Load Cell Cable Connection (Standard Gland Connector)
15
Load Cell Connections with over 30 Feet of Cable
15
Serial I/O Cable Installation
16
USB Interface and USB Cable Installation
18
Main PC Board I/O Functions Table
19
RB4/RB8 Relay Box Cable Wire Number to Relay Number Table
19
Optically Isolated Remote Inputs
20
AC Input Relay Board(S)
20
Pwc/Checkweigher Logic Level Output
22
AC Output Relay Board(S)
23
RB4C Relay J-Box
24
Main PCB (Figure No. 15)
25
Main PCB Jumpers
26
Re-Installing the Rear Panel
26
Keypad Functions
27
Annunciators
35
Setup and Calibration
37
Setup
38
Analog to Digital Filtering
43
Calibration
47
Setup Guardian Scale
51
Mode of Operation
51
Normal Scale
51
ID Storage
51
Checkweigher
51
Digital Fill Control
52
Preset Weight Comparator
54
Axle Weigher
56
Livestock Weigher
58
Serial Input/Output
59
Print Tab Settings
69
Fine Span Adjustment
71
Display High Resolution Weight
71
Key Lock out Function
71
Option Card Configuration
71
Setup Review
73
Calibration "C" Numbers
75
Accumulators
77
Troubleshooting
79
Error Codes
79
Before You Call Service
82
Diagnostic Test Mode
83
Calibration Seal Installation
84
ID Storage Operation
85
Digital Fill Control Mode Operation
93
Digital Fill Control ID Storage
101
Axle Weigher Operation Mode
105
Livestock Weigher Mode Operation
109
Model 210Dc
111
Local/Remote Setup
112
Part Identification
114
