8200-M585-O1 Rev D 210 Installation & Technical 50
SETUP AND CALIBRATION, CONT.
oper = 5 (Axle Weigher)
id= (ID Prompt)
The id= prompt enables an ID prompt before printing a ticket.
With the display showing id=, press the ENTER key to show the current value. If the
setting displayed is acceptable, press the ENTER key again to save it. Otherwise, using the
numeric keys, 0/NO or 1/YES, enter the new setting, then press the ENTER key to save it.
id=YES id=no
id= will be displayed when PRINT key is
pressed and printed on the ticket.
Normal print operation (no ID prompt) will
occur.
If you selected id=1 (Yes, ID Prompt), an additional prompt, "a clr=" will be displayed.
If you selected id=0 (No ID Prompt) proceed to A-d (A-d?) Analog to Digital Filtering.
A cLr= (Auto Clear ID)
The a clr= prompt determines whether the ID is automatically cleared after printing the
ticket. Note that it is only displayed when id= YES is selected.
With the display showing a clr=, press the ENTER key to show the current value. If the
setting displayed is acceptable, press the ENTER key again to save it. Otherwise, using the
numeric keys, 0/NO or 1/YES, enter the new setting, then press the ENTER key to save it.
A clr=YES a clr=no
Automatically clears the ID after the
ticket has printed.
ID is not cleared when ticket prints
and can be used for next transaction.
aUto?= (Automatic Axle Weigher)
The aUto?= (Automatic Axle Weigher) prompt determines whether the scale will be an
automatic axle weigher or will function as a standard axle weigher, using the PRINT and
(asterisk) and PRINT key functions
With the display showing aUto?=, press the ENTER key to show the current value. If the
setting displayed is acceptable, press the ENTER key again to save it. Otherwise, using the
numeric keys, 0/NO or 1/YES, enter the new setting, then press the ENTER key to save it.
aUto?=YES aUto?=no
Scale will be an automatic axle weigher Scale will be a standard axle weigher
aPAd?= (Axle Pads)
The aPAd?= (Axle Pads) prompt determines whether the indicator is connected to axle
pads or a full length truck scale to acquire axle weights.
With the display showing aPAd?=, press the ENTER key to show the current value. If the
setting displayed is acceptable, press the ENTER key again to save it. Otherwise, using the
numeric keys, 0/NO or 1/YES, enter the new setting, then press the ENTER key to save it.
aPAd?=YES aPAd?=no
Indicator is connected to axle pads Indicator is connected to full length
truck scale
NOTE: The difference between the APAD = YES and APAD = NO is if the user is using a
full length truck scale to acquire axle weights, or if they are using axle pads. If using a full
length truck scale the indicator will tare the gross weight after printing each axle. So the first
weight will be a gross weight, all remaining axles will be in net weight. If using axle pads all
weights will be gross weight.
