Cardinal 210 Installation And Technical Manual

8200-M585-O1 Rev D  210 Installation & Technical 48
SETUP AND CALIBRATION, CONT.
oPEr = 3 (Preset Weight Comparator)
P oUt= (Number of comparators)
The number of weight comparators can be from 1 to 8.
h oUt= (High state before cutoff)
If the comparator outputs are to be High before cutoff, answer YES to this prompt.
P-bAL= (Print-On-Balance)
With only one Preset selected (P oUt=1), an additional prompt P-bAL= (automatic Print
on Balance) will be displayed. If selected (P-bAL=YES), when the weight is above or
equals the preset value and all motion stops, weight will be printed (if a printer is attached).
Note that the weight must
go below 50% of the preset value before another print operation
can be performed.
If the setting displayed is acceptable, press the ENTER key to save it. Otherwise, using the
numeric keys, 0/NO or 1/YES, enter the new setting, then press the ENTER key to save it.
P-bAL=1 (Yes) P-bAL= 0 (No)
Automatic Print on Balance Enabled Automatic Print on Balance Disabled
id= (ID Prompt)
The id= prompt enables an ID prompt before printing a ticket.
With the display showing id=, press the ENTER key to show the current value. If the
setting displayed is acceptable, press the ENTER key again to save it. Otherwise, using the
numeric keys, 0/NO or 1/YES, enter the new setting, then press the ENTER key to save it.
id=1 (Yes) id=0 (No)
id= will be displayed when PRINT key is
pressed and printed on the ticket.
Normal print operation (no ID prompt) will
occur.
If you selected id=1 (Yes, ID Prompt), an additional prompt, "a clr=" will be displayed.
If you selected id=0 (No ID Prompt) proceed to A-d (A-d?) Analog to Digital Filtering.
A cLr= (Auto Clear ID)
The a clr= (Auto Clear ID) prompt determines whether the ID is automatically cleared
after printing the ticket. Note that it is only displayed when id= YES is selected.
With the display showing a clr=, press the ENTER key to show the current value. If the
setting displayed is acceptable, press the ENTER key again to save it. Otherwise, using the
numeric keys, 0/NO or 1/YES, enter the new setting, then press the ENTER key to save it.
A clr=1 (Yes) a clr=0 (No)
Automatically clears the ID after the
ticket has printed.
ID is not cleared when ticket prints
and can be used for next transaction.
