Carel pGD Touch - Schema 3: Rete Bacnet; Schema 4: Terminale Impianto in RS485 E Remoto in Ethernet; Schema 5: Terminale Impianto in Bacnet;Ip; Modbus TCP;IP E Remoto in Ethernet

22
pGD Touch +030221540 rel. 1.1 - 21.01.2015
ITA
6.4 Schema 3: rete BACnet
1
8
1
8
G
G0
PGD Touch: 4,3”, 7”, 10”, 13”
PCO1000BA0
BACnet MS/TP-pCOnet
J10
FieldBus card
BMS card
J11 pLAN
J25 BMS2
1
Tx/Rx
GND
BACnet MS/TP
(*) NOTA: inserire terminatore di linea/
NOTE: insert line termination
(*)
Dispositivo terze parti
Third party device
(*)
Fig. 6.d
6.5 Schema 4: terminale impianto in RS485 e remoto in Ethernet
1
8
1
8
G
G0
1
8
1
8
G
G0
PGD Touch: 4,3”, 7” (*)
J10
FieldBus card
BMS card
J11 pLAN
J25 BMS2
1
Tx/Rx
GND
J10
FieldBus card
BMS card
J11 pLAN
J25 BMS2
1
Tx/Rx
GND
PGD Touch: 4,3”, 7”, 10”, 13”
PlantVisorPro
(only Modbus)
connessioni in alternativa
/
alternative connections
Modbus TCP/IP
BACnet IP
(*)
NOTA: se i modelli 10” e 13” sono terminali impianto, aggiungere
la resistenza di terminazione sul dispositivo a fine linea/
Modbus RTU
A
B
NOTE: for the models 10” e 13” as plant terminal, add the resistance
in the last device of the net.
Fig. 6.e
6.6 Schema 5: terminale impianto in BACnet/IP / Modbus TCP/IP e remoto in Ethernet
PCO1000WB0
BACnet IP -pCOWeb
1
8
1
8
G
G0
Switch
pGD Touch: 4,3”, 7”
1
8
1
8
1
8
G
G0
pGD Touch: 4,3”, 7”
J10
FieldBus card
BMS card
J11 pLAN
J25 BMS2
1
Tx/Rx
GND
BACnet IP/ Modbus TCP/IP
Modbus TCP/IP
PlantVisorPro
connessioni in alternativa/
alternative connections
connessione opzionale/
optional connection
A
B
Dispositivo terze
parti / Third party
device
Fig. 6.f
