Carel pGD Touch User Manual

8
pGD Touch +030221540 rel. 1.1 - 21.01.2015
ENG
1.3 Accessories
1.3.1 230 Vac – 24 Vdc power supply (P/N
PGTA00TRF0)
Power supply for the 24 Vdc models (10.4”, 13.3”).
Fig. 1.a
1.3.2 RS485 cable adapter (P/N PGTA00CNV0)
Tis cable is used for connecting 10” and 13” terminals with DB9 connector
to pCO controllers over an RS485 network. The DB9 male connector on
the cable contains the polarisation resistors.
Fig. 1.b
1.3.3 SD card (not supplied)
On the 4.3” and 7” models predisposed, an SD card can be inserted
permanently for programmed data storage. Both normal and high
capacity (HC) cards can be used, up to 4 GB.
Fig. 1.c
1.3.4 Network cable (not supplied)
Fig. 1.d
