Carel pGD Touch User Manual

24
pGD Touch +030221540 rel. 1.1 - 21.01.2015
ENG
7. TECHNICAL SPECIFICATIONS
7.1 pGD Touch technical specications
These devices may only be used in residential, commercial and light industrial environments if special measures are taken to ensure conformity to IEC61000-
6-3.
Terminal
4,3” 7” 10” 13”
Display
Type LCD TFT LCD TFT TFT
Resolution 480 x 272 (WVGA) 800 x 480 (WVGA) 800 x 600, SVGA 1280 x 800, WVGA
Active display area 4.3” diagonal 7” diagonal, 16/9 10,4” diagonal 13,3” diagonal
Colours 64 K 64 K 64 K
Backlighting LED LED LED
Brightness adjustment Yes Yes 300 Cd/m
2
typ.
Visual angle Top/bottom/left/right
= 45/50/50/50 degrees
Top/bottom/left/right
= 60/50/60/60 degrees
-
Contrast (min) 250 ( = 0°) 250 ( = 0°) -
Response time (max) 54 ms Tr = 10 ms, Tf = 16 ms -
Colour temperature (CIE) white ( = 0°) x=0.24÷0.37
y=0.25÷0.39
white ( = 0°) x=0.249÷0.349
y=0.278÷0.378
-
Uniformity (min) 70 % 70 % -
Brightness (min) 140 cd/ m
2
180 cd/ m
2
250 cd/m
2
(typ)
System resources
Operating system Microsoft Windows CE 6.0 Microsoft Windows CE 6.0 Microsoft Windows CE 6.0
User memory 128 MB Flash 128 MB Flash 256 MB Flash
RAM 256 MB DDR2 256 MB DDR2 256 MB DDR
CPU ARM ARM MIPS
User interface
Touch screen Resistive Resistive Analog resistive
Signal LEDs 2 2 1 (dual core)
Interfaces
Ethernet port 1 Auto-MDIX 10/100 Mbit RJ45 female (1) Auto-MDIX 10/100 Mbit RJ45 female (3) 2 10/100 Mbit con switch integrato
Ethernet port 2 Auto-MDIX 10/100 Mbit RJ45 female (1) Auto-MDIX 10/100 Mbit RJ45 female (3)
USB port Host interface 2.0
USB type A female
500 mA max
Lmax cable < 1 m
Host interface 2.0
USB type A female
500 mA max
Lmax cable < 1 m
Host interface (1 vers. 2.0; 1 vers. 2.0 e 1.1)
Serial port 1: Com 1 RS485 max 115 Kb/s (2)
Plug-in screw connector, pitch 5.08
RS485 max 115 Kb/s (4)
Plug-in screw connector, pitch 5.08
RS232, RS485, RS422 configured by software
Serial port 2: Com 2 - RS485 max 115 Kb/s
Non optically-isolated. Plug-in screw connec-
tor, pitch 5.08
-
Memory card - - SD Card Slot
(1) Model PGDT04000F020 only
(2) Optically-isolated on model PGDT04000F020
(3) Model PGDT07000F120 only
(4) Optically-isolated on model PGDT07000F120
Note: the communication interfaces are not TNV, but rather SELV circuit
Aux port - - not active
Functions
Vector graphics Yes, SVG 1.0 support included Yes, SVG 1.0 support included
Dynamic objects Yes, visibility, position, rotation Yes, visibility, opacity, position, dimension,
rotation for many type of objects
Font TrueType Yes Yes
Multi-protocol Yes Yes, maximum 2 drivers
Logs and trends Yes. Limited to Flash memory capacity Yes. Limited to Flash memory capacity
Multilingue Yes, runtime language setting, only limited to memory space available Yes, runtime language setting, only limited to
memory space available
Recipes Yes. Limited to Flash memory capacity Yes. Limited to Flash memory capacity
Alarms Yes Yes
Event list Yes Yes
Password Yes Yes
Real Time Clock Yes, with backup battery Yes, with backup battery
Screen saver Yes Yes
Buzzer “Beep” when pressing the touchscreen (can be configured) “Beep” when pressing the touchscreen (can be
configured)
