25
pGD Touch +030221540 rel. 1.1 - 21.01.2015
ENG
Terminal
4,3” 7” 10” 13”
Electrical specications
Power supply
PGDT04000F02*:
24 Vac (-15…+10%) 50 Hz Max 0.6 A rms
(16VA);
12…30 Vdc (±5%) Max 0.5 Adc at 12 Vdc;
PGDT07000FR00:
24 Vac (-15…+10%), 50…60 Hz Max 1.2
A (24VA),
12 …30 Vdc ±5% Max 0,9 Adc at 12 Vdc;
24 Vdc (18...30 Vdc) 24 Vdc (18...30 Vdc)
PGDT04000FS0*:
24 Vac (-15…+10%) 50 Hz Max 0.5 A (14 VA);
12…30 Vdc (±5%) Max 0.4 Adc at 12 Vdc
PGDT07000F120: 24 Vac (-15…+10%),
50…60 Hz Max 1.2 A rms (27 VA);
12 …30 Vdc ±5% Max 1.0 Adc at 12 Vdc
Power input 6 W
(with 0.5 A load on USB)
12 W (minimum power cable
cross-section 0.5 mm
2
)
0,95 A a 24 Vdc (max) 1,15 A a 24 Vdc (max)
Fuse Automatic Automatic Automatic
Weight Approx 1 Kg Approx 1 Kg Approx 2.1 Kg Approx 2.8 Kg
Battery Not rechargeable, lithium, model
BR2330
Not rechargeable, lithium, model BR2330 Rechargeable, lithium, cannot be replaced
by the user
Software class and
structure
AA A
Resistance to heat and fire Cat. D Cat. D -
Immunity against voltage
surges
Cat. II Cat. II -
Insulation class Class III, to incorporate in class I or III devices Class III, to incorporate in class I or III
devices
-
Environmental conditions
Operating temperature -20 …60 °C 0…50 °C (vertical installation)
Storage temperature -20 …70 °C -20 …70 °C
Operating and storage
humidity
5 to 85 % relative humidity, non-condensing 5 to 85 % relative humidity, non-condensing
Protection rating IP65 (front); IP 20 (rear IP65 (front); IP 20 (rear
Degree of pollution Degree II Degree II
Standards compliance Compliant with European EMC and LVD directives.
UL certification.
CE mark
Tab. 7.a
