Posizione
Position
Tipo
Type
Funzione del fusibile
Fuse function
/ Engine ECU (+15)
/ 3-pole power socket (+15).
/ 3-pole power
socket (+30), cigarette lighter, diagnostic socket
/ Air Seat, foot throttle sensor, speed sensor,
front PTO
(1)
, deport
(1)
/ EHC, water in fuel switch, relay fuel heater
/ PTO switch, di-lock
switch, hand throttle sensor, di-lock pressure switch, VFR
(1),
4WD pressure
switch,
Dashboard (+15), HI-LO switches, trasmission
(2)
/ Dashboard
(+30), seat switch (+30), trasmission
/ Beacon light, working lights
/ Stop lights
/ Turn lights, horn
/ Warning lights
/ Low beam lights
/ High beam lights
/ Backlights, RH side position lights
/ LH side position lights
(1)
if tted
(2)
Only on 24+12 trasmission version
