revision 0 date: 07/19 doc. AG525990
6.9.4 - Front hitch - Check torque on attaching
screw of mounting frame
6.9.4 - Sollevatore anteriore - vericare coppia
di serraggio del telaio
 
v
Check the tighteness of the attaching screws from
Front Hitch to mounting frame.

6.9.5 - Front hitch - Lubricate all grease
ttings
6.9.5 - Sollevatore anteriore - Lubricare tutti
gli ingrassatori





On tractors equipped with the front hitch, apply
several shots of multi-purpose grease to greasing
points (1) and (2). Apply several shots of multi-
purpose grease to all other pins.
On tractors equipped with the adjustable front axle,
apply several shots of multi-purpose grease to ttings
(3), (4), and (5).
6.9.6 - heck hydraulic circuit accumulator
This operation must be done by an authorised service
centre.
6.9.6 - Controllare gli accumulatori del circuito
idraulico
󰀨


3

5
4

NOTA: prima di procedere alla
lubricazione delle parti munite
di ingrassatori pulire con cura
le superci di questi ultimi
ed assicurarsi che la sfera di
tenuta sia libera. A lubricazione
avvenuta rimuovere qualsiasi
residuo di grasso per evitare
che terriccio o polvere vi siano
trattenuti.
NOTE; Before lubricating any
parts provided with grease
nipples', carefully clean the
nipples surfaces and be sure that
their seal ball moves freely. After
the lubrication, remove any trace
of grease to avoid it to collect dirt
or dust.
