5
revision 0 date: 07/19 doc. AG525990
che devono essere
obbligatoriamente accoppiati
VERSIONE MOTHER REGULATION
che devono essere
obbligatoriamente accoppiati
Remove cap from pressure pick-up point (1) and (2)
for trailer brake, connect the trailer hose, making sure
that couplings are clean.
To activate the trailer hydraulic brake, press both brake
pedals that must compulsorily be coupled.Braking
eect depends on how much pressure is applied to
press brake pedals.
the warning light (3) on instrument panel, when is on,
has the double function of indicate malfunctions to the
braking system, and / or signal that the parking brake
is engaged.
It also allows, if pressed, to check the operation of the
trailer parking brake, simulating the insertion of the
handbrake, trying to move the tractor should meet the
resistance of the parking brake of the trailer
5.28 FRENATURA IDRAULICA PER RIMORCHIO
VERSIONE ITALIA (CUNA)
5.28 TRAILER HYDRAULIC BRAKING
ITALY VERSION (CUNA)
Remove cap from pressure pick-up point (1) for
trailer brake, connect delivery hose, making sure that
couplings are clean.
To activate the trailer hydraulic brake, press both brake
pedals that must compulsorily be coupledBraking
eect depends on how much pressure is applied to
press brake pedals.
MOTHER REGULATION VERSION
