- Pulizia/sostituzione del ltro aria primario
Smontaggio:
IMPORTANTE: fare attenzione a non danneggiare
o deformare l’anello di guida.
Montaggio:
- Sostituzione cartuccia interna di sicurezza
- Main air lter clean replacing
Disassembly:
- Open the hood by key (2)
- Loosen the screw (3) and unhook the clips (6) to
remove air inlet suction/cover.
- Pull out the primary lter element (5) out of the
lter housing.
Should it be necessary to clean cartridge (5) while
working in the eld, a temporary solution could be to
batter it on the palm of your hand.
IMPORTANT: Ensure not to damage or deform the
guiding ring.
Periodically, more frequently if you work in a very
dusty environment, or whenever the clogging light on
the control panel becomes visible, you need to clean
the external lter cartridge (5) with a jet of compressed
air less than 5 bar of pressure , direct from inside the
cartridge to the outside.
If the clogging light does not go out, replace the
cartridge.
Assembly:
Reinstall assembly by performing the removal
operations in reverse order.
- Secondary (safety) cartridge replacing
- Take out the secondary (safety) cartridge (7)
- Change lter if damaged.
IMPORTANT: Do not try to clean secondary
(safety) cartridge, always replace it.
- Fit the clean or new main cartridge (rst t the
rubber seal) fully home into its housing.
- Close cover and fasten retainers.
IMPORTANT: Do not close hood cover or start
engine before safely fastening the lter.
IMPORTANTE: non cercare di pulire la cartuccia
(di sicurezza) interna, ma sostituirla sempre.
IMPORTANTE: non chiudere il coperchio del
cofano o avviare il motore prima di aver ssato il
ltro in modo sicuro.
