61
6
revision 0 date: 07/19 doc. AG525990
Tractor empty weight (kg)
Load on the front axle of empty tractor (kg)
Load on the rear axle of empty tractor (kg)
Total weight of the front tool or ballast (kg)
Total weight of the rear tool or ballast (kg)
Distance between the centre of gravity of the front tool
or ballast and the front axle axis (m). Refer to the manual of the equipment or to measure.
Tractor wheelbase (m)
Distance between
the rear axle axis and the axis of the lower bar ball joints (m)
Distance between the axis
of the lower bar ball joints and the centre of gravity of the rear toolor ballast (m). Refer to the manual of the
equipment or to measure.
IMPORTANT: Before purchasing a tool, check
that all conditions are met using the following
calculations or by weighing the tractor/tool
combination.
IMPORTANTE: prima di acquistare un attrezzo,
vericare che siano soddisfatte tutte le condizioni,
facendo i calcoli seguenti o pesando l’insieme
trattore/attrezzo.
