6-MAINTENANCE
Replacementofthebattery
Toreplacethebatteriesproceedasfollows:
1.SetthebatterydisconnectswitchtoOposition(OFF
position)tocutoffanypowersupplyintheelectrical
systemofthemachine(referto3-43).
2.Removethecapsandthethreebolts(1).
3.Removetheleft-handsidepanel(2).
SMIL17MEX2385AB6
4.Removetheprotectivecapsanduseawrench[
13mm]toremovetheboltsindicatedinthegure.
5.Removetheleft-handshield.
SMIL16MEX1204AB7
6.Placeareceptacleofasuitablecapacityunderthe
drainplug(1).
7.Removethedrainplug(1)locatedatthebottomofthe
reservoir(2)anddrainthehydraulicoil.
8.Afterdraining,closethedrainplug(1).
SMIL16MEX2480AB8
9.Useawrench[13mm]toloosenthebolt(1),then
removethecoverbattery(2).
SMIL17MEX2718AB9
