3-CONTROLSANDINSTRUMENTS

Windshieldwasherreservoir

Thisreservoir,locatedintheleft-handsideofthecab,is

equippedwithanelectricpumpwhichisoperatedfromthe

wiperandwasherswitch.

NOTICE:neveroperatethewindshieldwashercontrol

whenthereservoirisempty.Thiscouldcausedamage

totheelectricpump.

Removethecaptoaddwindshieldwashinguid.

NOTICE:incoldweather,addanti-freezetothewind-

shieldwasherwater.

SMIL16MEX1425BA1

3-15
