3-CONTROLSANDINSTRUMENTS
Exteriorcontrols
Sidedoors
WARNING
Movingparts!
Makesureallentryandmechanicalaccessdoorsareproperlyclosedbeforeoperatingthemachine.
Failuretocomplycouldresultindeathorseriousinjury.
W0238A
Sidehood
Thesidehood(A)allowstoaccesstothecompartment
includingthehydraulicoiltankandthefueltank.
Engineaccessdoor
Theengineaccessdoor(B)allowstoaccesstotheengine
compartmentincludingthellingplugsoftheengineoil
andtheenginecoolant,theaircleaner,andthebattery
disconnectswitch.
SMIL16MEX0439BA1
