3-CONTROLSANDINSTRUMENTS
Opening
NOTICE:ifyouneedtoopentheright-handsidehood,
rstopentheengineaccessdoorandthentheright-hand
sidehood,inordertoavoiddamagetothesealbetween
thetwodoors.Seethedecallocatedoverthesidehood
handle,andperformtheprocedureasfollows.
SMIL16MEX0932AA2
1.Usethestarterkeytounlocktheenginedoor.
2.Usethehandletoopenthedoorandpressthehook
untilthedooriscompletelysecured.
SMIL16MEX0929AA3
3.Usethestarterkeytounlockthesidehood.
4.Usethehooktogentlyliftupthehoodandusethe
liftingstemtosecurethehood.
NOTICE:whileliftingthehood,makesurethehood
doesnotcontactthecab.Machinedamagecouldre-
sult.
NOTICE:neverleavetoolsinsidethecompartment.
SMIL16MEX0930AA4
