6-MAINTENANCE

Whennecessary

Bulbreplacement

Lightingintheoperatorcompartment

1.Removethetworetainingscrews.

SMIL16MEX0921AA1

2.Extracttheceilinglight(1)andpulloutthebulb(2).

SMIL16MEX0922AA2

3.Installanew5Wbulbintheceilinglight.

4.Puttheceilinglightbackintopositionandtightenby

meansofthetworetainingscrews.

SMIL16MEX0934AA3

6-60
