6-MAINTENANCE

Radiatorfan

Checktheradiatorfanevery500h

1.Rotatethecrankshaftbyusingtheenginebarring

gear.Checkforcracks,looserivets,andbentorloose

blades.

NOTE:neverpullorpryonthefan.

2.Checkthefantomakesureitissecurelymounted.

3.Tightenthecap-screwsifnecessary.Ifthefanisdam-

aged,consultyourCASECONSTRUCTIONdealerto

replacethefan.

SMIL16MEX0436AA1

6-50
