CASE CONSTRUCTION CX26C - Travel Reduction Gears

6-MAINTENANCE
Travelreductiongears
Replacethetravelreductiongearsoilevery1000h(After250hofoperationinbreak-inperiod)
Lubricant:CASEAKCELAGEARLUBE135HEP80W-90
Quantity:0.6L(0.2USgal)(pertravelreductiongear)
1.Parkthemachineonat,horizontalground.
2.Movethemachinesothatthedrainplug(1)comes
downtothelowestposition.
3.Stoptheengine,andremovethestarterkey.
4.Placeacontainerwithanappropriatecapacityunder
thetravelreductiongear.
5.Removethelevelplug(2).
6.Removethedrainplug(1).
NOTE:checktheconditionofthedrainedoil.Ifthereare
piecesofmetalorforeignobjectsintheoil,consultthe
CASECONSTRUCTIONdealer.
7.ReplacetheO-ringsealofthedrainplug(1).
8.Insertthedrainplug(1)withsealtapewrappedaround
it.
9.ReplacetheO-ringsealofthelevelplug(2)andthe
O-ringsealofthellplug(3).Insertthelevelplug(2)
withsealtapewrappedaroundit,thendothesamefor
thellplug(3).
10.Addoilthroughllport(3)untiltheoilcomesuptothe
bottomedgeoftheport(2).
11.Repeatsteps2to10fortheothertravelreduction
gear.
12.Runthemachineslowlytocheckthatthereareno
leaks.
SMIL16MEX0442AA1
6-54
