CASE CONSTRUCTION CX26C - Left-Hand Side Controls

3-CONTROLSANDINSTRUMENTS
Left-handsidecontrols
Left-handsidecontrols
SMIL16MEX0383EB1
(1)Safetylocklever(refertopage3-13)
(2)Left-handcontrollever(refertopage3-6)
(3)Armrest
(4)Enginespeedcontrollever(refertopage3-13)
(5)Mainlightswitch.Thisswitchactivatestheheadlight
andtheworklightintwosteps.
Therststepactivatestheheadlightandtheclusterillu-
minationlamp.
Thesecondstepactivatestheworklightandtheindicator
lampontheswitch.
(6)Hydraulicquickcouplingsystemactivationswitch(op-
tional)
Hydraulicquickcouplingsystemactivationswitch(optional)
Thehydraulicquickcouplingsystemactivationswitch(6)
isusedtoengageordisengagethehydraulicquickcou-
plingsystem.
Thisactivationswitchhasaslidingmechanism(A)forpre-
ventingerroneousswitchoperation.Slideslidingmecha-
nism(A)inthedirectionofthearrowtolockorunlockthe
device.
Thebuzzersoundswhenthehydraulicquickcouplingsys-
temactivationswitchispressedtodisengagethemoving
hook.Thebuzzerstopswhentheswitchisreleasedto
engagethemovinghook.
Toconnectordisconnectanattachment,proceedas
follows:
1.Placetheattachmentinthesafetypositionfordiscon-
necting.
2.Placethedozerbladecompletelyuppullingbackthe
dozerlever.
3.Pulllightlydozerbladedowntoreleasetheeventual
highpressureinsidedozerupline.
4.Slidetheswitchmechanism,thenpressandholdthe
hydraulicquickcouplingsystemactivationswitch.
NOTE:theleverofdozerpulledbackactivatesthe
pinsofthequickcoupler.
5.Pullbackwardthedozerleverfordisconnectingthe
attachment.
6.Releasetheswitch.
SMIL16MEX3181AA2
SMIL16MEX3221AA3
3-12
