9-ACCESSORIES
Quickcouplingsystem-Klactype
WARNING
Crushinghazard!
Neverputyourhandsinsidethequickcouplermechanism.Turnofftheengineandwaitforallmove-
menttostop.
Failuretocomplycouldresultindeathorseriousinjury.
W1542A
WARNING
Hazardtobystanders!
ALWAYSmakesuretheworkareaisclearofbystandersanddomesticanimalsbeforestartingthis
procedure.Knowthefullareaofmovementofthemachine.Donotpermitanyonetoenterthearea
ofmovementduringthisprocedure.
Failuretocomplycouldresultindeathorseriousinjury.
W0245A
NOTICE:thequickcouplerextendsthelengthofthearm.Makesuretochecktheoperatingrangeofthecoupled
attachmentinordertoavoidriskofstrikingthecaborthemachineframe.
NOTICE:neveroperatewithaquickcoupledhydraulicbreakerforanextendedperiodoftime,inordertoreducethe
riskofprematurewear,failuresorbreakageofthequickcoupler.Neverusethebreakerasalever,asthissubjects
thequickcouplercylindertostress.
NOTICE:besuretoreadandunderstandthequickcouplerOperator'sManualforproperinstallation,usageand
maintenance.
Quickcouplinghydrauliccircuitandconnections
Themachinecanprovideaquickcouplinghydrauliccir-
cuit.Thetworigidpipeslocatedbothonthetopofthearm
allowtoinstallproperlyandsafelythehosestoconnect
thehydraulicattachmenttothequickcouplinghydraulic
circuit.
SMIL17MEX2804BA1
Hydraulicconnections(A)ORFSISO843406–9/16–18UNF2A
Deliverypressure
Left-handhose
DischargepressureRight-handhose
9-24
