Attachmentengagement
WARNING
Misusehazard!
Followtheoperatinginstructionsinthischap-
ter.Anyotherpracticethathasnotreceived
thepriorapprovalofthemanufactureriscon-
sideredtobestrictlyforbidden.
Failuretocomplycouldresultindeathorse-
riousinjury.
W0281A
WARNING
Crushinghazard!
Thisoperationmaybedangerous.Youaread-
visedtowearsuitableclothingandrespectall
relevantsafetymessages.
Failuretocomplycouldresultindeathorse-
riousinjury.
W0283A
WARNING
Cuttinghazard!
Thisoperationcouldbedangerous.
Donotputyourhandsnearthemobileplate.
Ifthemobileplateisnotproperlylockedin
theengagedposition,themobileplatecould
suddenlydisengage.
Failuretocomplycouldresultindeathorse-
riousinjury.
W1491A
Toengagetheattachmenttothequickcouplingsystem:
1.Makesurethatthemachineandthebuckettobeused
areonatsolidground..
NOTICE:beforeusinganattachment,makesurethat
itstotalweightwhenfullyloadedDOESNOTEXCEED
themaximumliftcapacityofthemachine.
SMIL16MEX3210AB2
2.Beforeattachinganyequipment,thelockingplateof
thequickcouplingmustbeprepared.Operatethearm
controls,armandbuckettopositionthequickcoupling
horizontallytoataheightofabout1m(3.3ft)from
theground.Lockthemachinecontrols,downfromthe
cab,andtakethereleasetool.Insertthereleasetool
inthelockingplateasshowngureopposite.
NOTE:usethereleasetool(2)tomovethelocking
plateintoitsengageposition.
SMIL16MEX3211AB3
