9-ACCESSORIES
3.Pullthewrenchhandletoextractthelockingplate,until
itlatchesinplace.
4.Removethereleasetool,andstoreitinacompartment
ofthemachine.
5.Alignthearm(3)thatitisparalleltothebucket(4),
thenengagethepins(5)thatsecurethequickcoupler
tothebuckethooks.
NOTE:thebucketcylinder(6)mustbecompletelyre-
tracted:theangle(B)betweenthequickcouplerand
thebucketjawmustbeatleast100°.
SMIL16MEX3212AB4
NOTICE:completebucketengagementbypositioningthe
engagementpinsfullyinthehooksoftheadapterplate.
Donotengagethebucket,asshowninthegureoppo-
site,unlessthepinsarecompletelyinplace(detailA);do-
ingsomaycausethepinstobendunderstress,alsose-
riouslydamagingthequick-couplingsystemandattach-
ment.
SMIL17MEX0078AA5
WARNING
Crushinghazard!
Thisoperationmaybedangerous.Youaread-
visedtowearsuitableclothingandrespectall
relevantsafetymessages.
Failuretocomplycouldresultindeathorse-
riousinjury.
W0283A
6.Liftthebuckettoaheightof50cm(19.7in)(C)from
thegroundandengagetheright-handcontrolleverto
extendthebucketcylinder(6).Thebucketmakesthe
distinctivenoisewhenlocked.
SMIL16MEX3213BB6
9-26
