6-MAINTENANCE

Swingringgear

Greasetheswingringgearevery50h.

Lubricant:CASEAKCELA251HEPMULTI-PURPOSEGREASE

Swingringgear:onegreasetting

Usingagreasegun,injectgreaseofthespeciedtype

inthegreasepointsshowningure.

SMIL17MEX2657AA1

SMIL17MEX2649AA2

6-30
