3-CONTROLSANDINSTRUMENTS

3-CONTROLSANDINSTRUMENTS###_3_###

Accesstooperator'splatform

Doorandsteps

Cabdoor

CAUTION

Pinchhazard!

Becarefulnottogetyourhand,clothes,etc.

caughtinthedoorwhenclosingit.

Failuretocomplycouldresultinminoror

moderateinjury.

C0046A

Toopenthedoor,usethehandle(1)fromtheoutsideand

usethehandle(2)fromtheinside.

SMIL16MEX0364BA1

SMIL16MEX0365AA2

3-1
