CASE CONSTRUCTION CX26C - 9 ACCESSORIES; Direct Fit Buckets

9-ACCESSORIES
9-ACCESSORIES###_10_###
Directtbuckets
NOTICE:allattachmentshownonthismanualareexclusivetotheEuropeanMarket.Toallothermarketscontact
yourauthorizedCASECONSTRUCTIONdealer,beforepurchasinganattachment.
NOTE:contactyourauthorizedCASECONSTRUCTIONdealer,beforepurchasinganattachment.
Thedatashownbelowarereferredtoworkingoperationwiththedozerbladeupandthe117kg(257.9lb)counter-
weight.
Forcabconguration:
•
1.12m(44.09in)arm,minimumliftvalue:260kg(573.20lb).
•
1.35m(53.15in)arm,minimumliftvalue:240kg(529.11lb).
Forcanopyconguration:
•
1.12m(44.09in)arm,minimumliftvalue:230kg(507.06lb).
•
1.35m(53.15in)arm,minimumliftvalue:210kg(462.97lb).
Directtbucketsapplicationasfunctionofthearm(forcabversion)
Generalpurposebuckets
Arm
Capacity
ISO7451(Heaped)
WidthMass
1.12m
(44.09in)
1.35m
(53.15in)
0.027m³(0.035yd³)250mm(9.84in)38kg(83.78lb)
●
●
0.033m³(0.043yd³)300mm(11.81in)41kg(90.39lb)
●
●
0.040m³(0.052yd³)350mm(13.78in)43kg(94.80lb)
●
●
0.048m³(0.063yd³)400mm(15.75in)49kg(108.03lb)
●
●
0.055m³(0.072yd³)450mm(17.72in)55kg(121.25lb)
●
●
0.063m³(0.082yd³)500mm(19.69in)62kg(136.69lb)
●
●
0.085m³(0.111yd³)600mm(23.62in)72kg(158.73lb)
●
●
0.100m³(0.131yd³)700mm(27.56in)78kg(171.96lb)●(**)●(**)
Directtbucketsapplicationasfunctionofthearm(forcanopyversion)
Generalpurposebuckets
Arm
Capacity
ISO7451(Heaped)
WidthMass
1.12m
(44.09in)
1.35m
(53.15in)
0.027m³(0.035yd³)250mm(9.84in)38kg(83.78lb)
●
●
0.033m³(0.043yd³)300mm(11.81in)41kg(90.39lb)
●
●
0.040m³(0.052yd³)350mm(13.78in)43kg(94.80lb)
●
●
0.048m³(0.063yd³)400mm(15.75in)49kg(108.03lb)
●
●
0.055m³(0.072yd³)450mm(17.72in)55kg(121.25lb)
●
●
0.063m³(0.082yd³)500mm(19.69in)62kg(136.69lb)
●
●
0.085m³(0.111yd³)600mm(23.62in)72kg(158.73lb)●(**)●(**)
0.100m³(0.131yd³)700mm(27.56in)78kg(171.96lb)▲(**)■(**)
●Densityofmaterialupto1.6t/m
3
▲Densityofmaterialfrom1.4t/m
3
to1.6t/m
3
■Densityofmaterialfrom1.2t/m
3
to1.4t/m
3
♦Densityofmaterialunder1.2t/m
3
(*)Withthisbucket,toimprovediggingperformanceandstabilityitisrecommendedtouseadditionalcounterweight.
(**)Withthisbucket,toimprovediggingperformanceandstabilityitismandatorytouseadditionalcounterweight.
9-1
